Applicable Scenarios
Adaptable to petrochemical, power, metallurgy and environmental protection industries. Designed for on-site commissioning, parameter setting and troubleshooting of full-range HART smart instruments.
Product Features
Authoritative Compatibility
HART Foundation certified, fully compatible with HART instruments, and can replace imported 475 and TREX
Bluetooth Portable
Android OS + BLE 5.0 Bluetooth, compact body, supports wireless on-site operation
All-round power supply and battery life
Built-in with multiple types of power supplies and signal sources, it enables direct adjustment for non-powered instruments and features long-lasting battery life
Multilingual DD Resolution
Supports private menus for instruments, translation in 201 languages, and one-click localization of imported instruments into Chinese
Remote convenient operation and maintenance
Internet-based remote control of instruments eliminates the need for on-site trips, reducing costs and improving efficiency
Technical Parameters
| Project | Specifications |
|---|---|
| Operating System | Android |
| Bluetooth | Bluetooth BLE 5.0, with a range of approximately 10 meters |
| Power Output | Voltage: 24V/30mA; Current signal generator: 0–22mA; Built-in resistance: 250Ω |
| Battery Operating Time (per charge) | 24V/4mA: 30 hours; 24V/20mA: 10 hours; 24V off: 100 hours |
| Current Signal Generator | 0–22mA Software Settings |
| Software Settings | The instrument can be debugged remotely via the Internet |
| Localization | The DD menu can be translated into any language |
| HART Standard | FSK Physical Layer Specification, HCF_SPEC-054 |
| Interface Segregation Principle | HART Interface 1500V Isolation |
| Dimensions | 73mm x 52mm x 22mm (Length x Width x Height) |
| Ambient Temperature | -20 ℃ ~ +50 ℃ |
| Ambient Humidity | 0% ~ 95 %，no condensation |
